M Shape Diamond Segment for Cutting Granite and Sandstone High Frequency Brazed Welding

Large Image : M Shape Diamond Segment for Cutting Granite and Sandstone High Frequency Brazed Welding

Product Details:

Place of Origin:	Jiangxi, China
Brand Name:	LINXING Diamond Segment
Model Number:	LX-DS017

Payment & Shipping Terms:

Minimum Order Quantity:	1000 pieces
Price:	$1.00/pieces 1000-9999 pieces
Packaging Details:	Diamond Cutting Segment Packed by Plastic Box, LINXING LOGO Carton, etc.
Supply Ability:	10000 Set/Sets per Month

Contact Now

M Shape Diamond Segment for Cutting Granite and Sandstone High Frequency Brazed Welding

Description

Warranty:	None	Customized Support:	OEM, ODM, OBM
Raw Material:	Diamond Segment Powder. Metal Powder, Etc	Application:	Multi Blades Diamond Segment
Segment Shape:	M, K, Taper, Sandwich...	Size:	900mm-4200mm
Manutacturing Arts:	Sinter	Welding Method:	High Frequency Brazed (Suggest)
Product:	Diamond Segment	Quality:	A Grade
Packing:	Plastic Paper, LINXING LOGO Carton	Export Market:	Global
Port:	Shanghai, Shenzhen, Ningbo, Xiamen, Etc

Hight Quality M Shape Diamond Segment for Cutting Granite, Marble, Sandstone

Diamond Segments

Structure:

Diamond segments consist of small-size diamonds and metal bond materials, the metal bond materials may include the powders of Cu, Sn, Fe, Ag, Co, Ni, WC, Mo, etc.

Forms:

M shape, K shape, Taper shape, Flat shape, T shape, U shape, etc.

Use:

Cutting Granite, Marble, Sandstone, Limestone, Basalt, Concrete, etc.

Our diamond segments' advantage:

1. High percent of bond materials
2. High grade of diamonds
3. Over 15 years experence with hundreds of formula against different stones

4. Good sharpness, stable performance, long lifespan

5. Strict quality control
4. Keep 40-50 precent market share in China, Already acquired the customers' approval

Product Description

Segments for big diameter (900-3500mm) diamond single/multi blades

Diameter		Core Thickness (mm)	Segment Size (mm)	Segment Number (pcs/set)	Silent / Non Silent	Weld Method
mm	inch	Core Thickness (mm)	Segment Size (mm)	Segment Number (pcs/set)	Silent / Non Silent	Weld Method
900	36"	5	22(24)x6.0/6.6x12(15)(20)	64	non silent	high frequency
1000	40"	5.5	22(24)x6.4/7.0x12(15)(20)	70	non silent	high frequency
1200	48"	6	22(24)x7.4/8.0x12(15)(20)	80	non silent	high frequency
1400	55"	6.5	22(24)x7.8/7.4x12(15)(20)	92	non silent	high frequency
1600	64"	7.2	22(24)x8.4/9.0x12(15)(20)	108	non silent	high frequency
1800	72"	8	22(24)x9.2/9.8x12(15)(20)	120	non silent	high frequency
2000	80"	8	22(24)x9.5/10.5x12(15)(20)	128	non silent	high frequency
2200	88"	9	22(24)x10.5/11.5x15(20)	132	non silent	high frequency
2500	110"	9	22(24)x11.5/12.5x15(20)	140	non silent	high frequency
3000	120"	10	22(24)x12.5/13.5x15(20)	160	non silent	high frequency
3500	140"	10	22(24)x13.5/14.5x15(20)	180	non silent	high frequency

Segments for small diameter (300-800mm) diamond saw blade

Diameter		Core Thickness (mm)	Segment Size (mm)	Segment Number (pcs/set)	Silent / Non Silent	Weld Method
mm	inch	Core Thickness (mm)	Segment Size (mm)	Segment Number (pcs/set)	Silent / Non Silent	Weld Method
300	12"	2.0/2.2	40x2.8/3.0x8(10)(12)(15)	21	Silent/non silent	Laser/high frequency
350	14"	2.2/2.4	40x3.0/3.2x8(10)(12)(15)	24	Silent/non silent	Laser/high frequency
400	16"	2.6/2.8	40x3.6/3.8x8(10)(12)(15)	28	Silent/non silent	Laser/high frequency
450	18"	2.8/3.0	40x4.0/4.2x8(10)(12)(15)	32	Silent/non silent	Laser/high frequency
500	20"	2.8/3.0	40x4.0/4.2x8(10)(12)(15)	36	Silent/non silent	Laser/high frequency
600	24"	3.6	40x4.6x8(10)(12)(15)	42	Silent/non silent	Laser/high frequency
700	28"	4	40x5.2x8(10)(12)(15)	42	Silent/non silent	Laser/high frequency
800	32"	4.5	40x6.0x8(10)(12) (15)	46/57	Silent/non silent	Laser/high frequency

*Other specifications are available upon request

M Shape Diamond Segment for Cutting Granite and Sandstone High Frequency Brazed Welding 0

2500mm K shape diamond segments

M Shape Diamond Segment for Cutting Granite and Sandstone High Frequency Brazed Welding 1

1200mm M shape diamond segments

M Shape Diamond Segment for Cutting Granite and Sandstone High Frequency Brazed Welding 2

1400mm The ealier taper shape diamond segments

M Shape Diamond Segment for Cutting Granite and Sandstone High Frequency Brazed Welding 3

600mm Normal flat shape diamond segments

Company Information

M Shape Diamond Segment for Cutting Granite and Sandstone High Frequency Brazed Welding 4

Jiangxi LINXING Diamond Tools Co.,Ltd., is a professional and key manufacturer of diamond tools in China, located in Pharmacentical and Chemical Industry Zone, Tianfanjie Town, Poyang County, Shangrao, Jiangxi. The main products are all kind of stone cutting tools, including diamond segment, diamond wire saw, 105-800mm diamond saw blade.

Today, especially LINXING' diamond segments have been able to keep 40/50 percent market share in China, this feature allow and prompt all LINXING person to generalize our products worldwide.

The friends, we look forward to working with you sincerely.

M Shape Diamond Segment for Cutting Granite and Sandstone High Frequency Brazed Welding 5

M Shape Diamond Segment for Cutting Granite and Sandstone High Frequency Brazed Welding 6

Why choose us?

1. A leading factory of diamond tools industry in China

2. Approved quality with very competitive price

3. Good sharpness, stable performance, high cutting efficiency and long lifespan

4. Strict quality control system, accept inspection by 3rd party

5. Custom design can be meet upon request, small trial order is available in any time

6. Easy communication, LINXING professional sales team will always answer you in time, besides, friendly and helpful after sales service is always there for you.

Packaging & Shipping

M Shape Diamond Segment for Cutting Granite and Sandstone High Frequency Brazed Welding 7

M Shape Diamond Segment for Cutting Granite and Sandstone High Frequency Brazed Welding 8

1.Sample order, customers could choose Fast Express DHL/UPS/FedEx/TNT, door to door.

2.Bulk order, the goods would be sent to you by Sea or by Air, port or airport receiving.
3.Using our agent or your freight agent is up to customers.
4.Delivery time: 7-15 days for samples; 15-30 days for normal bulk order.

M Shape Diamond Segment for Cutting Granite and Sandstone High Frequency Brazed Welding 9

M Shape Diamond Segment for Cutting Granite and Sandstone High Frequency Brazed Welding 10
