Linsing Super Thin Sharp Saw Blade For Cut Tile Porcelain Marble J Slot Cutting Disc Disk

Linsing Super Thin Sharp Saw Blade For Cut Tile Porcelain Marble J Slot Cutting Disc Disk
Linsing Super Thin Sharp Saw Blade For Cut Tile Porcelain Marble J Slot Cutting Disc Disk Linsing Super Thin Sharp Saw Blade For Cut Tile Porcelain Marble J Slot Cutting Disc Disk Linsing Super Thin Sharp Saw Blade For Cut Tile Porcelain Marble J Slot Cutting Disc Disk Linsing Super Thin Sharp Saw Blade For Cut Tile Porcelain Marble J Slot Cutting Disc Disk Linsing Super Thin Sharp Saw Blade For Cut Tile Porcelain Marble J Slot Cutting Disc Disk Linsing Super Thin Sharp Saw Blade For Cut Tile Porcelain Marble J Slot Cutting Disc Disk

Large Image :  Linsing Super Thin Sharp Saw Blade For Cut Tile Porcelain Marble J Slot Cutting Disc Disk

Product Details:
Place of Origin: Jiangxi, China
Brand Name: Linsing
Model Number: Diamond circular saw blade
Payment & Shipping Terms:
Minimum Order Quantity: 10 pieces
Price: $25.40/pieces 10-99 pieces
Packaging Details: The inner packaging is plastic film and the outer packaging is carton. If the customer orders a large quantity, it will be packed in wooden cases and wooden frames.
Supply Ability: 2000 Piece/Pieces per Day High Quality Diamond Saw Blade
Contact Now

Linsing Super Thin Sharp Saw Blade For Cut Tile Porcelain Marble J Slot Cutting Disc Disk

Description
Warranty: None Blade Thickness: 0.014in, 0.012
Blade Width: 1 1/2IN, 3/4IN, 1/2in, 1 1/4IN, 5/8in, 3/8in, 1/8IN, 1/4in Arbor Size: 7/8IN, 10mm, 5/8in
Teeth Per Inch: 10, 24 Teeths: 140, 144
Blade Length: 6in, 6 1/2in, 10in Blade Diameter: 18in, 12in, 14in
Edge Height: 0.315in(8mm), 0.472in(12mm) Process Type: HOT PRESS, High Frequency Welded, Laser Welded
Customized Support: OEM, ODM, OBM Finishing: Ti-coated
Size: 350mm, 350mm Grade: Industrial
Product Name: Diamond Saw Cutting Blade Application: Marble Cutting
Usage: Wet Cutting Feature: High Speed.Straight Smooth Edge
Advantage: High Efficiency Blade Material: 65 Mn Steel
MOQ: 5Piece Shape: Fan Or Arc Shape
Machine: Laser Bridge Saw Machine Or Handld Cutting Machine Port: Shanghai, Shenzhen, Ningbo, Xiamen, Etc

Diamond Saw Blade For Marble

Marble saw blade is a kind of diamond tool used for marble cutting It has the characteristics of long life and good continuity , used on saw blade for cutting block and slab

Product features:
1. Cutting in high speed without chipping.
2. Strict quality inspection, long lifespan.
3. Stable cutting performance, high cost-effective.
4. Silent and non-silent blade are available.
Production specification:

Blade Diameter(inch/mm)

Steel Core Thickness(mm)

Segment Specification(mm)

Segment No.(pcs)

Φ12”/300

2.2

42/40x3.2x8(10)

22

Φ14”/350

2.2/2.4

42/40x3.4x8(10)

25

Φ16”/400

2.6

42/40x3.6x8(10)

29

Φ18”/450

2.8/3.0

40x4x8(10)

32

Φ20”/500

3.0/3.2

40x4.2x8(10)

36

Φ24”/600

3.6/3.8

40x5x8(10)

42

Φ28”/700

4

40x5.2x8(10)

50

Φ32”/800

4.5

40x6x8(10)

57

Φ36”/900

5.0

24x7.5x8(10,12,13,15)

64

Φ40”/1000

5.0

24x7.5x8(10,12,13,15)

70

Φ48”/1200

5.5

24x8.0x8(10,12,13,15)

80

Φ52”/1300

6.0

24x8.5x8(10,12,13,15)

88

Φ56”/1400

6.5

24x9.0x8(10,12,13,15)

92

Φ64”/1600

7.2

24x9.2x8(10,12,13,15)

108

Φ72”/1800

7.5

24x10x8(10,12,13,15)

120

Φ80”/2000

8.0

24x10.5x8(10,12,13,15)

128

Φ88”/2200

8.0/9.0

24x11x8(10,12,13,15)

132

Φ100”/2500

9.0

24x11x8(10,12,13,15)

140

Φ120”/3000

9.5

24x12x8(10,12,13,15)

160

Φ140”/3500

9.5

24x12x8(10,12,13,15)

180

Other specifications are available upon request.
