Professional 115mm Laser Welded Diamond Segmented Saw Blade for Concrete Brick Cutting

Professional 115mm Laser Welded Diamond Segmented Saw Blade for Concrete Brick Cutting
Professional 115mm Laser Welded Diamond Segmented Saw Blade for Concrete Brick Cutting Professional 115mm Laser Welded Diamond Segmented Saw Blade for Concrete Brick Cutting Professional 115mm Laser Welded Diamond Segmented Saw Blade for Concrete Brick Cutting Professional 115mm Laser Welded Diamond Segmented Saw Blade for Concrete Brick Cutting Professional 115mm Laser Welded Diamond Segmented Saw Blade for Concrete Brick Cutting Professional 115mm Laser Welded Diamond Segmented Saw Blade for Concrete Brick Cutting

Large Image :  Professional 115mm Laser Welded Diamond Segmented Saw Blade for Concrete Brick Cutting

Product Details:
Place of Origin: Jiangxi, China
Brand Name: Linsing
Model Number: Diamond laser disc
Payment & Shipping Terms:
Minimum Order Quantity: 20 pieces
Price: $1.80/pieces >=20 pieces
Packaging Details: inner carton+outer wooden box
Supply Ability: 5000 Piece/Pieces per Day
Contact Now

Professional 115mm Laser Welded Diamond Segmented Saw Blade for Concrete Brick Cutting

Description
Warranty: None Blade Thickness: 1.8mm
Blade Width: 10mm Arbor Size: 22.23mm
Teeths: 8 Blade Length: 10mm
Blade Diameter: 115mm Process Type: Laser Welded
Customized Support: OEM, ODM, OBM Finishing: White
Size: 115mm Grade: Industrial
Application: Concrete Cutting MOQ: 20 Pcs For One Size Disc
Material: Diamond Powder+Alloy Steel Feature: Lower Noise
Machine: Handheld Angle Grinder Service: After-sale Service
Diameter: 115*22.23mm Technology: Electroplated
Color: Customized Color Packing: Inner Box
Port: Xiamen, Shanghai, Guangzhou

Electroplating technology makes all diamond particles adhere to the steel core, high diamond exposure rate provides efficient work performance.

Laser Weld Diamond Saw Blade
This saw blade adopts a laser welding process. Laser welding technology enables the manufacturing process to be highly automated, resulting in greatly improved stability and stronger adhesion of the diamonds to the metal substrate. The result is improved efficiency, cutting life, and operator safety.

Product features:
1. Excellent comprehensive cutting performance.
2. Working fast without chipping and noise.
3. High efficiency in the process of cutting saw blades.
4. Low cost and friendly surroundings with our saw blade.
5. The saw blade works smoothly and makes the surface flat.
6. Our diamond saw blade is widely used for cutting stones.
Product specification:

Blade

Diameter

(inch/mm)

Bore(mm)

Segment

Thickness

(mm)

Segment

Height

(pcs)

Φ4”/105

20/0.787"

1.8

8/10/12

Φ4.3”/110

20/0.787"

1.8

8/10/12

Φ4.5”/115

22.23/0.875"

1.8

8/10/12

Φ5”/125

22.23/0.875"

2.0

8/10/12

Φ6”/150

22.23/0.875"

2.2

8/10/12

Φ7”/180

22.23/0.875"

2.4

8/10/12

Φ8”/200

22.23/0.875"

2.4

8/10/12

Φ9”/230

22.23/0.875"

2.6

8/10/12

Φ10”/250

22.23/0.875"

2.8

8/10/12



Diameter

(inch/mm)

Steel Core Thickness

(mm)

Segment Specification

(mm)

Segment No.

(pcs)

Φ4”/105

1.4

32×2.2×10(2)

8

Φ4.5”/115

1.4

32×2.2×10(2)

9

Φ5”/125

1.4

32×2.2×10(2)

10

Φ6”/150

1.4

32×2.2×10(2)

12

Φ7”/180

1.8

32×2.6×10(2)

14

Φ8”/200

1.8

32×2.6×10(2)

16

Φ9”/230

2.0

38×2.8×10(2)

16

Φ10”/250

2.0

38×2.8×10(2)

17

Φ12”/300

2.2

40×3.2×10(2)

21

Φ14”/350

2.2

40×3.2×10(2)

24

Φ16”/400

2.2

40×3.2×10(2)

28

Other specifications are available upon request.
