40*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting

Certification
China Jiangxi Linxing Diamond Tools Co., Ltd. certification
I'm Online Chat Now

40*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting

40*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting
40*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 40*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 40*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 40*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 40*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 40*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting

Large Image :  40*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting

Product Details:
Place of Origin: Jiangxi, China
Brand Name: LINSING
Model Number: 40*7*15
Payment & Shipping Terms:
Minimum Order Quantity: 100 pieces
Price: $0.66 - $1.05/pieces
Packaging Details: carton
Supply Ability: 100000 Piece/Pieces per Day

40*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting

Description
Warranty: NONE Customized Support: OEM, ODM, OBM
Application: Granite Color: Picture Color
Grade: A-Grade Product Name: Diamond Segment
Usage: Granite Cutting Material: Diamond Powder
Keywords: Diamond Grinding Segment Feature: Fast Cutting
Advantage: Long Life Size: 40*7*15
Port: Shanghai, Shenzhen, Ningbo, Xiamen, Etc

Diamond Segment For Granite Cutting

Granite cutting segment is a diamond tool for cutting granite Linxing s granite cutting segments has the characteristics of wide variety, strong pertinence, long life, high sharpness and high cost performance

Product Features:
1. Good sharpness and high efficiency without chipping.
2. Strict QC for stable cutting performance.
3. Long life span with high cost-effective.
4. Segment is easy for opening.

Product Specification:

Blade Diameter(inch/mm)

Steel Core Thickness(mm)

Segment Specification(mm)

Segment No.(pcs)

Φ12”/300

2.2

40x3.2x10(12,15, 20)

21

Φ14”/350

2.2/2.4

40x3.2x10(12,15, 20)

24

Φ16”/400

2.6

40x3.6x10(12,15, 20)

28

Φ18”/450

2.8/3.0

40x4x10(12,15, 20)

32

Φ20”/500

3.0/3.2

40x4.2x10(12,15, 20)

36

Φ24”/600

3.6/3.8

40x5x10(12,15, 20)

42

Φ28”/700

4

40x5.2x10(12,15, 20)

50

Φ32”/800

4.5

40x6x10(12,15, 20)

46

Φ36”/900

5.0

24x7.0/6.2x15(13,20)

64

Φ40”/1000

5.0

24x7.0/6.2x15(13,20)

70

Φ48”/1200

5.5

24x7.4/6.6x15(13,20)

80

Φ52”/1300

6.0

24x8.0/7.2x15(13,20)

88

Φ56”/1400

6.5

24x8.4/7.6x15(13,20)

92

Φ64”/1600

7.2

24x9.2/8.4x15(13,20)

108

Φ72”/1800

7.5

24x10.0/9.2x15(13,20)

120

Φ80”/2000

8.0

24x10.6/9.8x15(13,20)

128

Φ88”/2200

8.0/9.0

24x11.0/10.2x15(13,20)

132

Φ100”/2500

9.0

24x11.4/10.6x15(13,20)

140

Φ120”/3000

9.5

24x12.4/11.6x15(13,20)

160

Φ140”/3500

9.5

24x12.4/11.6x15(13,20)

180

Other specifications are available upon request.40*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 040*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 140*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 240*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 340*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 440*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 540*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 640*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 740*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 840*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 940*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 1040*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 1140*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 1240*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 1340*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 1440*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 1540*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 1640*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 1740*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 1840*7*15 Diamond Grinding Segment in Picture Color for Granite Marble Concrete Cutting 19
