13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM

13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM
13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM

Large Image :  13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM

Product Details:
Place of Origin: Jiangxi, China
Brand Name: LINSING
Model Number: 24*7.6/8.4*15MM
Payment & Shipping Terms:
Minimum Order Quantity: 200 pieces
Price: $0.53/pieces 200-4999 pieces
Packaging Details: The inner packaging is plastic film and the outer packaging is carton. If the customer orders a large quantity, it will be packed in wooden cases and wooden frames.
Supply Ability: 50000 Piece/Pieces per Day Dia.250-3500 diamond circular saw blade
Contact Now

13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM

Description
Warranty: 3 Years Customized Support: OEM, ODM, OBM
Material: High Grade Diamond Usage: 300mm-3500mm Saw Blade
Segment Height: 13/15/20mm Steel Core: 5.0-7.2mm
Type: M Shape Technology: Cold Press And Hot Press Sintered
Color: Black, Silver Segment: Multi-layer Segments
Certificate: ISO9001 Packing: Inner Box+Outer Box
Port: Shanghai, Shenzhen, Ningbo, Xiamen, Etc

Diamond Segment For Multi-Saw Blade

Multi segment is a kind of diamond tool used in Italian multiblade cutting machine, Chinese multiblade bridge saw machine, or chinese single column multiblade cutting machine It is usually used to cut stone blocks, and it has the characteristics of high cutting efficiency and stable cutting

 13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 0

Product Features:
1. The segment has good sharpness against different stone cutting.
2. Long lifespan with high cost-effective.
3. Strict QC for stable cutting performance.
4. Segment shape is easy for opening.



Product Specification:

Multiblade segment for granite cutting

Diameter(mm)

Steel Core Thickness(mm)

Segment Specification(mm)

Φ1000 (600-2000)

5.0

24x7.0/6.2x15 (13,20)

Φ1200 (530-2800)

5.5

24x7.4/6.6x15 (13,20)

Φ1400 (460-2800)

6.5

24x8.4/7.6x15 (13,20)

Φ1600 (460-3000)

7.2

24x9.2/8.4x15 (13,20)

Other specifications are available upon request.



Multiblade segment for marble cutting

Diameter(mm)

Steel Core Thickness(mm)

Segment Specification(mm)

Φ1200

4.5

24x5.5x8 (10)

Φ1200

5.0

24x6.0x8 (10)

Φ1200

6.5

24x7.5x8 (10)

Φ1200

7.0

24x8.0x8 (10)

Other specifications are available upon request.

13/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 113/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 213/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 313/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 413/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 513/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 613/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 713/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 813/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 913/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 1013/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 1113/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 1213/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 1313/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 1413/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 1513/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 1613/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 1713/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 1813/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 1913/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 2013/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 2113/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 2213/15/20mm Silver Multiblade Diamond Segment for Marble Granite Cutting 5.5-6.5MM 23
