Style M Shape Diamond Segment for Granite Stone Block Cutting Exported Worldwide

Large Image : Style M Shape Diamond Segment for Granite Stone Block Cutting Exported Worldwide

Product Details:

Place of Origin:	Jiangxi, China
Brand Name:	LINXING
Certification:	TUV
Model Number:	LXK-MB003

Payment & Shipping Terms:

Minimum Order Quantity:	1000 pieces
Price:	$0.73/pieces 1000-9999 pieces
Packaging Details:	Diamond Cutting Segment Packed by Plastic Box, LINXING LOGO Carton, etc.
Supply Ability:	10000 Set/Sets per Month Exporter Diamond Segment

Contact Now

Style M Shape Diamond Segment for Granite Stone Block Cutting Exported Worldwide

Description

Warranty:	None	Customized Support:	OEM, ODM, OBM
Material:	Diamond+Metal Powder	Segment Shape:	M, K, Taper, Sandwich...
Manutacturing Arts:	Sinter	Welding Method:	High Frequency Brazed (Suggest)
Product:	Diamond Segment For Granite Cutting	Packing:	Plastic Paper, LINXING LOGO Carton
Export Market:	Global	Style:	M Shape Diamond Segment
Grade:	A-Grade	Port:	Shanghai, Shenzhen, Ningbo, Xiamen, Etc

Granite Cutting Machine Multi Blade Diamond Segment For Stone Block Cutting

Diamond Segments

Structure:

Diamond segments consist of small-size diamonds and metal bond materials, the metal bond materials may include the powders of Cu, Sn, Fe, Ag, Co, Ni, WC, Mo, etc.

Forms:

M shape, K shape, Taper shape, Flat shape, T shape, U shape, etc.

Use:

Cutting Granite, Marble, Sandstone, Limestone, Basalt, Concrete, etc.

Our diamond segments' advantage:

1. High percent of bond materials
2. High grade of diamonds
3. Over 15 years experence with hundreds of formula against different stones

4. Good sharpness, stable performance, long lifespan

5. Strict quality control
4. Keep 40-50 precent market share in China, Already acquired the customers' approval

Product Description

LINXING M and K shape segment with unique "<<" is the most scientific design for stone block cutting, it is easy ofr diamond opening and cutting speed with high cutting efficiency, surely, it is also reducing noise and saving cutting cost for stone factory.

Specification:

Segments for 300-800mm diamond saw blade
Diameter		Core Thickness (mm)	Segment Dimension (mm)			No. of Teeth
mm	inch	Core Thickness (mm)	Length	Thickness	Height	No. of Teeth
300	12"	2.0/2.2	40	2.8/3.0	8/10/12/15	21
350	14"	2.2/2.4	40	3.0/3.2	8/10/12/15	24
400	16"	2.6/2.8	40	3.4/3.6	8/10/12/15	28
450	18"	2.8/3.0	40	4.0/4.2	8/10/12/15	32
500	20"	2.8/3.0	40	4.0/4.2	8/10/12/15	36
600	24"	3.6	40	4.6	8/10/12	42
700	28"	4	40	5.2	8/10/12	42
800	32"	4.5	40	6.0	8/10/12	46/57
Segments for 900-3500mm single/multi blades
Diameter		Core Thickness (mm)	Segment Dimension (mm)			No. of Teeth
mm	inch	Core Thickness (mm)	Length	Thickness	Height	No. of Teeth
900	36"	5	22/24	6.0/6.6	12/13/15	64
1000	40"	5.5	22/24	6.4/7.0	12/13/15	70
1200	48"	6	22/24	7.4/8.0	12/13/15	80
1400	55"	6.5	22/24	7.8/8.4	12/13/15	92
1600	64"	7.2	22/24	8.4/9.0	12/13/15	108
1800	72"	8	22/24	9.2/9.8	12/13/15/20	120
2000	80"	8	22/24	9.5/10.5	12/13/15/20	128
2200	88"	9	22/24	10.5/11.5	12/13/15/20	132
2500	110"	9	22/24	11.5/12.5	12/13/15/20	140
3000	120"	10	22/24	12.5/13.5	12/13/15/20	160
3500	140"	10	22/24	13.5/14.5	12/13/15/20	180

*Other specifications are available upon request.
