Diamond Wet Grinding Wheel Countertop Milling Edge Profiling Tool for Surface Grinding

Diamond Wet Grinding Wheel Countertop Milling Edge Profiling Tool for Surface Grinding
Diamond Wet Grinding Wheel Countertop Milling Edge Profiling Tool for Surface Grinding Diamond Wet Grinding Wheel Countertop Milling Edge Profiling Tool for Surface Grinding Diamond Wet Grinding Wheel Countertop Milling Edge Profiling Tool for Surface Grinding Diamond Wet Grinding Wheel Countertop Milling Edge Profiling Tool for Surface Grinding Diamond Wet Grinding Wheel Countertop Milling Edge Profiling Tool for Surface Grinding Diamond Wet Grinding Wheel Countertop Milling Edge Profiling Tool for Surface Grinding

Large Image :  Diamond Wet Grinding Wheel Countertop Milling Edge Profiling Tool for Surface Grinding

Product Details:
Place of Origin: Jiangxi, China
Brand Name: LINSING
Model Number: Diamond stubbing wheel
Payment & Shipping Terms:
Minimum Order Quantity: 10 pieces
Price: $48.00/pieces 10-99 pieces
Packaging Details: Diamond stubbing grinding wheel Packed by Plastic Box, LINXING LOGO Carton, etc.
Supply Ability: 10000 Piece/Pieces per Month diamond stubbing wheel
Contact Now

Diamond Wet Grinding Wheel Countertop Milling Edge Profiling Tool for Surface Grinding

Description
Warranty: None Customized Support: OEM, ODM, OBM
Type: Abrasive Disc Product Name: CNC Stubbing Wheel
Application: Stone Material: Diamond
Usage: Surface Grinding Shape: Customzied
Grit Size: Customzied Feature: Long Life High Performance
MOQ: 1 Set Machine: CNC Grinding Wheel
Bond: Metal Bond And Resin Bond

CNC Stubbing Wheel

CNC stubbing wheel is used for surface milling and material removal on granite and engineered stone.

1.CNC stubbling wheel  is designed to calibrate the thickness of the countertop where it overhangs the cabinets.

This is important because not all slabs are equal thickness which can throw off your seams at install.



2.This cnc  stubbing wheel also allows you to create a smooth to the touch finish on the underside of tops,because one way to tell if the countertop installation is done by a professional installer is to check the underside of the overhanging countertop, like a bar top.

If done professionally, one can tell that the underside has been smoothed out and all of the rough surface is gone, leaving a nice smooth surface. The ladies will also appreciate this kind of an installation, as it will not snag their pantyhose or scrape their knees under the bar countertop.



CNC stubbling wheel Advantages

                   Calibrates about 2 inches in width of the underside of countertop's edge

  • Grinds down the rough surfaces and leaves them smooth to the touch
  • One of the determining factors of a professional countertop installation
  • Feed Rate: 500-1200mm/min
  • RPM: 5000-5500





Specification(mm) Inner Hole(mm) Segment Height(mm)
50×20 50 20
86×20/30/40 50 20
90×30 50 30
100×20/30/40 50 30

Other specifications are available upon request
