High Frequency Welding 800mm Saw Blade Diamond Segments for Cutting Andesite Granite

Name: High Frequency Welding 800mm Saw Blade Diamond Segments for Cutting Andesite Granite
Brand: LINSING
SKU: 24*7.6/8.4*15MM
Price: 0.69 USD
Availability: InStock
Rating: 5 (190 reviews)

All Products

Diamond Cutting Segment
(301)

Diamond Saw Blades
(281)

Diamond Wire Saw
(121)

Polishing Stone Abrasives
(345)

Diamond Drilling Tools
(47)

Diamond Cutting Discs
(101)

Floor Grinding Tools
(9)

Diamond Profiling Tools
(46)

Diamond Milling Tools
(35)

Stone Processing Equiments
(59)

PDC Cutter Tools
(2)

Ungrouped
(14)

Certification

I'm Online Chat Now

High Frequency Welding 800mm Saw Blade Diamond Segments for Cutting Andesite Granite

Large Image : High Frequency Welding 800mm Saw Blade Diamond Segments for Cutting Andesite Granite

Product Details:

Place of Origin:	Jiangxi, China
Brand Name:	LINSING
Model Number:	247.6/8.415MM

Payment & Shipping Terms:

Minimum Order Quantity:	200 pieces
Price:	$0.69/pieces 200-499 pieces
Packaging Details:	The inner packaging is plastic film and the outer packaging is carton. If the customer orders a large quantity, it will be packed in wooden cases and wooden frames.
Supply Ability:	100000 Piece/Pieces per Day Dia.350-3000 diamond circular saw blade

Contact Now

High Frequency Welding 800mm Saw Blade Diamond Segments for Cutting Andesite Granite

Description

Warranty:	3 Years	Customized Support:	OEM, ODM, OBM
Material:	Diamond Powder + Metal Powder	Diamond Saw Blade:	300mm - 3500mm
Segment Type:	Multi-layer Type	Technology:	Hot Press,cold Press
Segment Height:	13/15/20mm	Advantage:	High Performance
Certificate:	ISO9001	Brand:	Diamond Segment Manufacturer
Application:	High Frequency Welding	Product Name:	Granite Cutting Tools
Port:	Shanghai, Shenzhen, Ningbo, Xiamen, Etc

Diamond Segment For Granite Cutting

Granite cutting segment is a diamond tool for cutting granite Linxing s granite cutting segments has the characteristics of wide variety, strong pertinence, long life, high sharpness and high cost performance.

Product Features:
1. Good sharpness and high efficiency without chipping.
2. Strict QC for stable cutting performance.
3. Long life span with high cost-effective.
4. Segment is easy for opening.

Product Specification:

Blade Diameter(inch/mm)	Steel Core Thickness(mm)	Segment Specification(mm)	Segment No.(pcs)
Φ12”/300	2.2	40x3.2x10(12,15, 20)	21
Φ14”/350	2.2/2.4	40x3.2x10(12,15, 20)	24
Φ16”/400	2.6	40x3.6x10(12,15, 20)	28
Φ18”/450	2.8/3.0	40x4x10(12,15, 20)	32
Φ20”/500	3.0/3.2	40x4.2x10(12,15, 20)	36
Φ24”/600	3.6/3.8	40x5x10(12,15, 20)	42
Φ28”/700	4	40x5.2x10(12,15, 20)	50
Φ32”/800	4.5	40x6x10(12,15, 20)	46
Φ36”/900	5.0	24x7.0/6.2x15(13,20)	64
Φ40”/1000	5.0	24x7.0/6.2x15(13,20)	70
Φ48”/1200	5.5	24x7.4/6.6x15(13,20)	80
Φ52”/1300	6.0	24x8.0/7.2x15(13,20)	88
Φ56”/1400	6.5	24x8.4/7.6x15(13,20)	92
Φ64”/1600	7.2	24x9.2/8.4x15(13,20)	108
Φ72”/1800	7.5	24x10.0/9.2x15(13,20)	120
Φ80”/2000	8.0	24x10.6/9.8x15(13,20)	128
Φ88”/2200	8.0/9.0	24x11.0/10.2x15(13,20)	132
Φ100”/2500	9.0	24x11.4/10.6x15(13,20)	140
Φ120”/3000	9.5	24x12.4/11.6x15(13,20)	160
Φ140”/3500	9.5	24x12.4/11.6x15(13,20)	180

Other specifications are available upon request.

High Frequency Welding 800mm Saw Blade Diamond Segments for Cutting Andesite Granite 1
