Concrete Stone Marble Granite Block Cutting Triangle Diamond Segments with Long Lifespan

Concrete Stone Marble Granite Block Cutting Triangle Diamond Segments with Long Lifespan
Concrete Stone Marble Granite Block Cutting Triangle Diamond Segments with Long Lifespan Concrete Stone Marble Granite Block Cutting Triangle Diamond Segments with Long Lifespan Concrete Stone Marble Granite Block Cutting Triangle Diamond Segments with Long Lifespan Concrete Stone Marble Granite Block Cutting Triangle Diamond Segments with Long Lifespan Concrete Stone Marble Granite Block Cutting Triangle Diamond Segments with Long Lifespan Concrete Stone Marble Granite Block Cutting Triangle Diamond Segments with Long Lifespan

Large Image :  Concrete Stone Marble Granite Block Cutting Triangle Diamond Segments with Long Lifespan

Product Details:
Place of Origin: Jiangxi, China
Brand Name: Linsing
Model Number: Marble cutting segment
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pieces
Price: $0.86/pieces 1000-9999 pieces
Packaging Details: Plastic+Carton
Supply Ability: 50000 Piece/Pieces per Day Marble cutting segment
Contact Now

Concrete Stone Marble Granite Block Cutting Triangle Diamond Segments with Long Lifespan

Description
Warranty: None Customized Support: OEM, ODM, OBM
Product Name: Diamond Segment For Marble Application: Marble, Limestone, Other Soft Stones
Material: Diamond + Metal Powder Usage: Wet Use
Keywords: Stone Cutting Tip Size: 40*5*10mm
Grade: A-Grade Feature: High Performance Cutting
Shape: Triangle Machine: Single Saw Blade Block Cutter
Port: Xiamen Port

Diamond Segment For Marble Cutting

The segment used for marble processing, mainly used for cutting block, slab and thin plate etc.



Product Features:
1. Good sharpness and high efficiency without chipping;
2. Strict QC for stable cutting performance;
3. Long lifespan with high cost-effective;
4. Segment is easy for opening.

Product Specification:



Blade Diameter(inch/mm)

Steel Core Thickness(mm)

Segment Specification(mm)

Segment No.(pcs)

Φ12”/300

2.2

42/40x3.2x8(10,12,15)

22

Φ14”/350

2.2/2.4

42/40x3.4x8(10,12,15)

25

Φ16”/400

2.6

42/40x3.6x8(10,12,15)

29

Φ18”/450

2.8/3.0

40x4x8(10,12,15)

32

Φ20”/500

3.0/3.2

40x4.2x8(10,12,15)

35

Φ24”/600

3.6/3.8

40x5x8(10,12,15)

42

Φ28”/700

4

40x5.2x8(10,12,15)

50

Φ32”/800

4.5

40x6x8(10,12,15)

57

Φ36”/900

5.0

24x7.5x8(10,12,13,15)

64

Φ40”/1000

5.0

24x7.5x8(10,12,13,15)

70

Φ48”/1200

5.5

24x8.0x8(10,12,13,15)

80

Φ52”/1300

6.0

24x8.5x8(10,12,13,15)

88

Φ56”/1400

6.5

24x9.0x8(10,12,13,15)

92

Φ64”/1600

7.2

24x9.2x8(10,12,13,15)

108

Φ72”/1800

7.5

24x10x8(10,12,13,15)

120

Φ80”/2000

8.0

24x10.5x8(10,12,13,15)

128

Φ88”/2200

8.0/9.0

24x11x8(10,12,13,15)

132

Φ100”/2500

9.0

24x11x8(10,12,13,15)

140

Φ120”/3000

9.5

24x12x8(10,12,13,15)

160

Φ140”/3500

9.5

24x12x8(10,12,13,15)

180

Other specifications are available upon request.
