Customized Support OBM Diamond Metal Powder 2400mm Mining Saw Tip Quarry Machine

Large Image : Customized Support OBM Diamond Metal Powder 2400mm Mining Saw Tip Quarry Machine

Product Details:

Place of Origin:	Jiangxi, China
Brand Name:	Linsing
Model Number:	G22581

Payment & Shipping Terms:

Minimum Order Quantity:	136 pieces
Price:	$0.73/pieces >=136 pieces
Packaging Details:	The inner packaging is plastic film and the outer packaging is carton. If the customer orders a large quantity, it will be packed in wooden cases and wooden frames.
Supply Ability:	50000 Piece/Pieces per Day

Contact Now

Customized Support OBM Diamond Metal Powder 2400mm Mining Saw Tip Quarry Machine

Description

Customized Support:	OEM, ODM, OBM	Product Name:	Quarry Diamond Segment
Application:	Granite Mining	Material:	Diamond + Metal Powder
Advantage:	Long Service Life	Shape:	M Shape
MOQ:	136pcs	Shipping:	FEDEX UPS EMS DHL TNT
Service:	After-sales Service	Payment:	TT; WESTERN UNION
Packing:	Carton	Port:	Shanghai, Shenzhen, Ningbo, Xiamen, Etc

Diamond Segment For Quarrying&Mining

Diamond quarrying segment is a kind of diamond tool product commonly used in granite mining The product is mainly used for the mining of granite stone blocks, it is used on the mine circular saw By laying the track, the circular saw can mine the stone blocks in the round-trip process.

Product features:
1. Good Sharpness: speedy cutting, low machine current, mining blocks are square with good flat surface.
2. Long Life: Reducing the times of re-welding, achieving high cutting linear meters.
3. Good Adaptability: Suitable for different stone and various complicated mining environments.
Product Specification:
Double-blades Combinations:
D2200/D3300; D2200/D3600; D2400/D3300; D2400/D3600mm

Blade Diameter(mm)	Steel Core Thickness(mm)	Segment Specification(mm)	Segment No.(pcs)
Φ2200/2400	9.5/10	22x13.1/13.9x15	132/140
Φ3300/3600	9.5/10	22x12.4/11.6x15	160/180

Triple-blades Combinations:
D2400/D3600/D4200; D2600/D3800/D4600; D2600/D3800/D4800

Blade Diameter(mm)	Steel Core Thickness(mm)	Segment Specification(mm)	Segment No(pcs)
Φ2400/2600	12	22x15.6/16.4x15	142
Φ2400/2600	12	24x15.6/16.4x20	142
Φ3600/3800	12	22x14.6/15.4x15	180
Φ3600/3800	12	24x14.6/15.4x20	180
Φ4200/4600/4800	12	22x13.6/14.4x15	210
Φ4200/4600/4800	12	24x13.6/14.4x20	210

Other specifications are available upon request.

Product Description

Customized Support OBM Diamond Metal Powder 2400mm Mining Saw Tip Quarry Machine 0

Linxing products

Customized Support OBM Diamond Metal Powder 2400mm Mining Saw Tip Quarry Machine 11

Packaging & Shipping

Customized Support OBM Diamond Metal Powder 2400mm Mining Saw Tip Quarry Machine 13

Our Services

Customized Support OBM Diamond Metal Powder 2400mm Mining Saw Tip Quarry Machine 15
