Small Gang Saw Machine Stone Cutting Tools 204.5/510 Flat Shape Segment For Marble

Large Image : Small Gang Saw Machine Stone Cutting Tools 20*4.5/5*10 Flat Shape Segment For Marble

Product Details:

Place of Origin:	Jiangxi, China
Brand Name:	LINXING
Model Number:	LXK-0177

Payment & Shipping Terms:

Minimum Order Quantity:	1000 pieces
Price:	$0.87/pieces 1000-4999 pieces
Packaging Details:	Diamond Cutting Segment Packed by Plastic Box, LINXING LOGO Carton, etc.
Supply Ability:	100000 Piece/Pieces per Month Marble Gang Saw Segment

Contact Now

Small Gang Saw Machine Stone Cutting Tools 204.5/510 Flat Shape Segment For Marble

Description

Customized Support:	OEM, ODM, OBM	Raw Material:	Diamond. Metal Powder, Etc
Application:	Multiblade	Segment Shape:	Flat Shape
Manutacturing Arts:	Sinter	Welding Method:	High Frequency Brazed (Suggest)
Product:	Diamond Cutting Segment	Quality:	A Grade Segments
Packing:	Plastic Paper, LINXING LOGO Carton	Export Market:	Global
Keywords:	Marble Gang Saw Segment	Port:	Shanghai, Shenzhen, Ningbo, Xiamen, Etc

Stone Cutting Teeth Marble Gang Saw Segment for Diamond Cutting Tool

Diamond Segments

Structure:

Diamond segments consist of small-size diamonds and metal bond materials, the metal bond materials may include the powders of Cu, Sn, Fe, Ag, Co, Ni, WC, Mo, etc.

Forms:

M shape, K shape, Taper shape, Flat shape, T shape, U shape, etc.

Use:

Cutting Granite, Marble, Sandstone, Limestone, Basalt, Concrete, etc.

Our diamond segments' advantage:

1. High percent of bond materials
2. High grade of diamonds
3. Over 15 years experence with hundreds of formula against different stones

4. Good sharpness, stable performance, long lifespan

5. Strict quality control
4. Keep 40-50 precent market share in China, Already acquired the customers' approval

Product Description

LINXING M and K shape segment with unique "<<" is the most scientific design for stone block cutting, it is easy ofr diamond opening and cutting speed with high cutting efficiency, surely, it is also reducing noise and saving cutting cost for stone factory.

Specification:

Segments for 300-800mm diamond saw blade
Diameter		Core Thickness (mm)	Segment Dimension (mm)			No. of Teeth
mm	inch	Core Thickness (mm)	Length	Thickness	Height	No. of Teeth
300	12"	2.0/2.2	40	2.8/3.0	8/10/12/15	21
350	14"	2.2/2.4	40	3.0/3.2	8/10/12/15	24
400	16"	2.6/2.8	40	3.4/3.6	8/10/12/15	28
450	18"	2.8/3.0	40	4.0/4.2	8/10/12/15	32
500	20"	2.8/3.0	40	4.0/4.2	8/10/12/15	36
600	24"	3.6	40	4.6	8/10/12	42
700	28"	4	40	5.2	8/10/12	42
800	32"	4.5	40	6.0	8/10/12	46/57
Segments for 900-3500mm single/multi blades
Diameter		Core Thickness (mm)	Segment Dimension (mm)			No. of Teeth
mm	inch	Core Thickness (mm)	Length	Thickness	Height	No. of Teeth
900	36"	5	22/24	6.0/6.6	12/13/15	64
1000	40"	5.5	22/24	6.4/7.0	12/13/15	70
1200	48"	6	22/24	7.4/8.0	12/13/15	80
1400	55"	6.5	22/24	7.8/8.4	12/13/15	92
1600	64"	7.2	22/24	8.4/9.0	12/13/15	108
1800	72"	8	22/24	9.2/9.8	12/13/15/20	120
2000	80"	8	22/24	9.5/10.5	12/13/15/20	128
2200	88"	9	22/24	10.5/11.5	12/13/15/20	132
2500	110"	9	22/24	11.5/12.5	12/13/15/20	140
3000	120"	10	22/24	12.5/13.5	12/13/15/20	160
3500	140"	10	22/24	13.5/14.5	12/13/15/20	180

*Other specifications are available upon request.
