Smooth and Precise Cutting A Grade Diamond Saw Blades with OBM Customized Support

Large Image : Smooth and Precise Cutting A Grade Diamond Saw Blades with OBM Customized Support

Product Details:

Place of Origin:	Jiangxi, China
Brand Name:	Linsing
Certification:	TUV&GS
Model Number:	Vaccum Brazed Diamond Saw Blade

Payment & Shipping Terms:

Minimum Order Quantity:	10 pieces
Price:	$28.00/pieces 10-99 pieces
Packaging Details:	The inner packaging is plastic film and the outer packaging is carton. If the customer orders a large quantity, it will be packed in wooden cases and wooden frames.
Supply Ability:	1000 Piece/Pieces per Day Dia.250-450 diamond circular saw blade

Contact Now

Smooth and Precise Cutting A Grade Diamond Saw Blades with OBM Customized Support

Description

Warranty:	None	Customized Support:	OEM, ODM, OBM
Product Name:	Vaccum Brazed Diamond Saw Blade	Application:	For Cutiing Marble Stone
Material:	Diamond+Metal	Diameter:	D400
MOQ:	10	Grade:	A+ Grade
Package:	Plastic&Carton&Wodden Frame	Type:	Round/ Circular Type
Brand:	Linsing

Product features:
1. Cutting in high speed without chipping.
2. Strict quality inspection, long lifespan.
3. Stable cutting performance, high cost-effective.
4. Silent and non-silent blade are available.
Production specification:

Blade Diameter(inch/mm)	Steel Core Thickness(mm)	Segment Specification(mm)	Segment No.(pcs)
Φ12”/300	2.2	42/40x3.2x8(10)	22
Φ14”/350	2.2/2.4	42/40x3.4x8(10)	25
Φ16”/400	2.6	42/40x3.6x8(10)	29
Φ18”/450	2.8/3.0	40x4x8(10)	32
Φ20”/500	3.0/3.2	40x4.2x8(10)	36
Φ24”/600	3.6/3.8	40x5x8(10)	42
Φ28”/700	4	40x5.2x8(10)	50
Φ32”/800	4.5	40x6x8(10)

Φ36”/900

5.0

24x7.5x8(10,12,13,15)

Φ40”/1000

5.0

24x7.5x8(10,12,13,15)

Φ48”/1200

5.5

24x8.0x8(10,12,13,15)

Φ52”/1300

6.0

24x8.5x8(10,12,13,15)

Φ56”/1400

6.5

24x9.0x8(10,12,13,15)

Φ64”/1600

7.2

24x9.2x8(10,12,13,15)

108

Φ72”/1800

7.5

24x10x8(10,12,13,15)

120

Φ80”/2000

8.0

24x10.5x8(10,12,13,15)

128

Φ88”/2200

8.0/9.0

24x11x8(10,12,13,15)

132

Φ100”/2500

9.0

24x11x8(10,12,13,15)

140

Φ120”/3000

9.5

24x12x8(10,12,13,15)

160

Φ140”/3500

9.5

24x12x8(10,12,13,15)

180

Other specifications are available upon request.
