10mm Arbor Size 400mm 16 Inch Diamond Segmented Cutting Disc for Bridge Saw Machines

10mm Arbor Size 400mm 16 Inch Diamond Segmented Cutting Disc for Bridge Saw Machines
10mm Arbor Size 400mm 16 Inch Diamond Segmented Cutting Disc for Bridge Saw Machines 10mm Arbor Size 400mm 16 Inch Diamond Segmented Cutting Disc for Bridge Saw Machines 10mm Arbor Size 400mm 16 Inch Diamond Segmented Cutting Disc for Bridge Saw Machines 10mm Arbor Size 400mm 16 Inch Diamond Segmented Cutting Disc for Bridge Saw Machines 10mm Arbor Size 400mm 16 Inch Diamond Segmented Cutting Disc for Bridge Saw Machines 10mm Arbor Size 400mm 16 Inch Diamond Segmented Cutting Disc for Bridge Saw Machines

Large Image :  10mm Arbor Size 400mm 16 Inch Diamond Segmented Cutting Disc for Bridge Saw Machines

Product Details:
Place of Origin: Jiangxi, China
Brand Name: LINSING
Certification: TUV
Model Number: Circular saw blade
Payment & Shipping Terms:
Minimum Order Quantity: 10 pieces
Price: $32.00/pieces 10-99 pieces
Packaging Details: Diamond Saw blade Packed by Carton, LINXING LOGO Carton, etc.
Supply Ability: 10000 Set/Sets per Month Arix diamond saw blade
Contact Now

10mm Arbor Size 400mm 16 Inch Diamond Segmented Cutting Disc for Bridge Saw Machines

Description
Warranty: None Blade Thickness: 0.014in, 0.032in, 0.05in, 0.02in, 0.035in, 0.018in, 0.042in, 0.025in
Blade Width: 1 1/2IN, 3/4IN, 1/2in, 1 1/4IN, 5/8in, 3/8in, 1/8IN, 1/4in, 1in, 3/16in, Other Arbor Size: 7/8IN, 10mm, 5/8in
Teeth Per Inch: 10, 24, 28 Teeths: 28
Blade Length: 6in, 6 1/2in, 10in, 14in Blade Diameter: 18in, 12in, 14in
Edge Height: 0.315in(8mm), 0.472in(12mm) Process Type: HOT PRESS, High Frequency Welded, Laser Welded, Cold PRESS
Customized Support: OEM, ODM, OBM Finishing: Ti-coated
Size: D350mm Grade: Industrial
Product Name: Arix Saw Blade Application: Granite Cutting
Usage: Wet Working Material: Tungsten Carbide Steel
Advantage: High Efficiency Feature: High Speed.Straight Smooth Edge
Machine: Bridge Saw Manchines Quality Grade: A++ A+
Technology: Hot Pressing Sintered

Arix Diamond Circular Saw Blade

Arix saw blade(arrayed saw blade) is a high-quality sawing product with high sharpness and long service life, which is specially used for granite cutting. Its sharpness is about 30% higher than that of general saw blades. The incision is smooth, without edge collapse, with excellent stable cutting performance.





Product Feature:
1. Higher cutting efficiency and low energy consumption than normal blade;
2. Effectively reduce noise and protect the environment;
3. It can be widely used on various power machines;
4. Application: Granite cutting.
Product Specification:

Diameter(inch/mm)

Steel Core Thickness(mm)

Segment Specification(mm)

Segment No.(pcs)

Φ12”/300

2.2

43/40×3.2×12(15,20)

21

Φ14”/350

2.2

43/40×3.2×12(15,20)

24

Φ16”/400

2.6

43/40×3.6×12(15,20)

28

Φ18”/450

3.0

43/40×4.2×12(15,20)

32

Other specifications are available upon request.
