Granite Cutting 7/8IN Arbor Size Diamond Cutting Disc for Multi Blade Rip Saw Machine

Granite Cutting 7/8IN Arbor Size Diamond Cutting Disc for Multi Blade Rip Saw Machine
Granite Cutting 7/8IN Arbor Size Diamond Cutting Disc for Multi Blade Rip Saw Machine Granite Cutting 7/8IN Arbor Size Diamond Cutting Disc for Multi Blade Rip Saw Machine Granite Cutting 7/8IN Arbor Size Diamond Cutting Disc for Multi Blade Rip Saw Machine Granite Cutting 7/8IN Arbor Size Diamond Cutting Disc for Multi Blade Rip Saw Machine Granite Cutting 7/8IN Arbor Size Diamond Cutting Disc for Multi Blade Rip Saw Machine Granite Cutting 7/8IN Arbor Size Diamond Cutting Disc for Multi Blade Rip Saw Machine

Large Image :  Granite Cutting 7/8IN Arbor Size Diamond Cutting Disc for Multi Blade Rip Saw Machine

Product Details:
Place of Origin: Jiangxi, China
Brand Name: LINSING
Certification: TUV
Model Number: Circular saw blade
Payment & Shipping Terms:
Minimum Order Quantity: 10 pieces
Price: $32.00/pieces 10-99 pieces
Packaging Details: Diamond Saw blade Packed by Carton, LINXING LOGO Carton, etc.
Supply Ability: 10000 Set/Sets per Month Arix diamond saw blade
Contact Now

Granite Cutting 7/8IN Arbor Size Diamond Cutting Disc for Multi Blade Rip Saw Machine

Description
Warranty: None Blade Thickness: 0.014in, 0.032in, 0.05in, 0.02in, 0.035in, 0.018in, 0.042in, 0.025in
Blade Width: 1 1/2IN, 3/4IN, 1/2in, 1 1/4IN, 5/8in, 3/8in, 1/8IN, 1/4in, 1in, 3/16in, Other Arbor Size: 7/8IN, 10mm, 5/8in
Teeth Per Inch: 10, 24, 28 Teeths: 28
Blade Length: 6in, 6 1/2in, 10in, 14in Blade Diameter: 18in, 12in, 14in
Edge Height: 0.315in(8mm), 0.472in(12mm) Process Type: HOT PRESS, High Frequency Welded, Laser Welded, Cold PRESS
Customized Support: OEM, ODM, OBM Finishing: Ti-coated
Size: D350mm Grade: Industrial
Product Name: Arix Saw Blade Application: Granite Cutting
Usage: Wet Working Material: Tungsten Carbide Steel
Advantage: High Efficiency Feature: High Speed.Straight Smooth Edge
Machine: Bridge Saw Manchines Quality Grade: A++ A+
Technology: Hot Pressing Sintered

Arix Diamond Circular Saw Blade

Arix saw blade(arrayed saw blade) is a high-quality sawing product with high sharpness and long service life, which is specially used for granite cutting. Its sharpness is about 30% higher than that of general saw blades. The incision is smooth, without edge collapse, with excellent stable cutting performance.





Product Feature:
1. Higher cutting efficiency and low energy consumption than normal blade;
2. Effectively reduce noise and protect the environment;
3. It can be widely used on various power machines;
4. Application: Granite cutting.
Product Specification:

Diameter(inch/mm)

Steel Core Thickness(mm)

Segment Specification(mm)

Segment No.(pcs)

Φ12”/300

2.2

43/40×3.2×12(15,20)

21

Φ14”/350

2.2

43/40×3.2×12(15,20)

24

Φ16”/400

2.6

43/40×3.6×12(15,20)

28

Φ18”/450

3.0

43/40×4.2×12(15,20)

32

Other specifications are available upon request.
