LINSING Diamond Segment for Granite Block Cutting Stone Cutting Tip Saw Blade Tools

LINSING Diamond Segment for Granite Block Cutting Stone Cutting Tip Saw Blade Tools
LINSING Diamond Segment for Granite Block Cutting Stone Cutting Tip Saw Blade Tools LINSING Diamond Segment for Granite Block Cutting Stone Cutting Tip Saw Blade Tools LINSING Diamond Segment for Granite Block Cutting Stone Cutting Tip Saw Blade Tools LINSING Diamond Segment for Granite Block Cutting Stone Cutting Tip Saw Blade Tools LINSING Diamond Segment for Granite Block Cutting Stone Cutting Tip Saw Blade Tools LINSING Diamond Segment for Granite Block Cutting Stone Cutting Tip Saw Blade Tools

Large Image :  LINSING Diamond Segment for Granite Block Cutting Stone Cutting Tip Saw Blade Tools

Product Details:
Place of Origin: Jiangxi, China
Brand Name: LINSING
Model Number: granite segment
Payment & Shipping Terms:
Minimum Order Quantity: 100 pieces
Price: $0.88/pieces 100-999 pieces
Contact Now

LINSING Diamond Segment for Granite Block Cutting Stone Cutting Tip Saw Blade Tools

Description
Warranty: None Customized Support: OEM, ODM, OBM
Product Name: Diamond Segment For Granite Application: Granite
Material: Diamond Usage: Wet
Advantage: High Wear Resistance Feature: High Performance Cutting
Grade: A-Grade

Diamond Segment For Granite Cutting

Granite cutting segment used for cutting granite. Linxing's granite cutting segments has the characteristics of wide variety, strong pertinence, long life, high sharpness and high cost performance.



Product Features:
1. Good sharpness and high efficiency without chipping;
2. Strict QC for stable cutting performance;
3. Long life span with high cost-effective;
4. Segment is easy for opening.

Product Specification:

Blade Diameter(inch/mm)

Steel Core Thickness(mm)

Segment Specification(mm)

Segment No.(pcs)

Φ12”/300

2.2

40x3.2x10(12,15, 20)

21

Φ14”/350

2.2/2.4

40x3.2x10(12,15, 20)

24

Φ16”/400

2.6

40x3.6x10(12,15, 20)

28

Φ18”/450

2.8/3.0

40x4x10(12,15, 20)

32

Φ20”/500

3.0/3.2

40x4.2x10(12,15, 20)

36

Φ24”/600

3.6/3.8

40x5x10(12,15, 20)

42

Φ28”/700

4

40x5.2x10(12,15, 20)

50

Φ32”/800

4.5

40x6x10(12,15, 20)

46

Φ36”/900

5.0

24x7.0/6.2x15(13,20)

64

Φ40”/1000

5.0

24x7.0/6.2x15(13,20)

70

Φ48”/1200

5.5

24x7.4/6.6x15(13,20)

80

Φ52”/1300

6.0

24x8.0/7.2x15(13,20)

88

Φ56”/1400

6.5

24x8.4/7.6x15(13,20)

92

Φ64”/1600

7.2

24x9.2/8.4x15(13,20)

108

Φ72”/1800

7.5

24x10.0/9.2x15(13,20)

120

Φ80”/2000

8.0

24x10.6/9.8x15(13,20)

128

Φ88”/2200

8.0/9.0

24x11.0/10.2x15(13,20)

132

Φ100”/2500

9.0

24x11.4/10.6x15(13,20)

140

Φ120”/3000

9.5

24x12.4/11.6x15(13,20)

160

Φ140”/3500

9.5

24x12.4/11.6x15(13,20)

180

Other specifications are available upon request.
