LINSING A-Grade WC CO Cutting and Grinding Diamond Segment for Marble Granite Cutting

LINSING A-Grade WC CO Cutting and Grinding Diamond Segment for Marble Granite Cutting
LINSING A-Grade WC CO Cutting and Grinding Diamond Segment for Marble Granite Cutting LINSING A-Grade WC CO Cutting and Grinding Diamond Segment for Marble Granite Cutting LINSING A-Grade WC CO Cutting and Grinding Diamond Segment for Marble Granite Cutting LINSING A-Grade WC CO Cutting and Grinding Diamond Segment for Marble Granite Cutting LINSING A-Grade WC CO Cutting and Grinding Diamond Segment for Marble Granite Cutting LINSING A-Grade WC CO Cutting and Grinding Diamond Segment for Marble Granite Cutting

Large Image :  LINSING A-Grade WC CO Cutting and Grinding Diamond Segment for Marble Granite Cutting

Product Details:
Place of Origin: Jiangxi, China
Brand Name: LINSING
Certification: ISO9001:2008
Model Number: Marble cutting tools
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pieces
Price: $0.86/pieces 1000-9999 pieces
Contact Now

LINSING A-Grade WC CO Cutting and Grinding Diamond Segment for Marble Granite Cutting

Description
Warranty: None Customized Support: OEM, ODM, OBM
Product Name: Diamond Segment Application: Cutting Marble
Material: WC+CO Usage: Wet Cutting
Keywords: Diamond Cutting Tips Advantage: High Wear Resistance
Color: Customized Color Machine: Bridge Saw
Grade: A-Grade

Diamond Segment For Marble Cutting

The segment used for marble processing, mainly used for cutting block, slab and thin plate etc.



Product Features:
1. Good sharpness and high efficiency without chipping;
2. Strict QC for stable cutting performance;
3. Long lifespan with high cost-effective;
4. Segment is easy for opening.

Product Specification:



Blade Diameter(inch/mm)

Steel Core Thickness(mm)

Segment Specification(mm)

Segment No.(pcs)

Φ12”/300

2.2

42/40x3.2x8(10,12,15)

22

Φ14”/350

2.2/2.4

42/40x3.4x8(10,12,15)

25

Φ16”/400

2.6

42/40x3.6x8(10,12,15)

29

Φ18”/450

2.8/3.0

40x4x8(10,12,15)

32

Φ20”/500

3.0/3.2

40x4.2x8(10,12,15)

35

Φ24”/600

3.6/3.8

40x5x8(10,12,15)

42

Φ28”/700

4

40x5.2x8(10,12,15)

50

Φ32”/800

4.5

40x6x8(10,12,15)

57

Φ36”/900

5.0

24x7.5x8(10,12,13,15)

64

Φ40”/1000

5.0

24x7.5x8(10,12,13,15)

70

Φ48”/1200

5.5

24x8.0x8(10,12,13,15)

80

Φ52”/1300

6.0

24x8.5x8(10,12,13,15)

88

Φ56”/1400

6.5

24x9.0x8(10,12,13,15)

92

Φ64”/1600

7.2

24x9.2x8(10,12,13,15)

108

Φ72”/1800

7.5

24x10x8(10,12,13,15)

120

Φ80”/2000

8.0

24x10.5x8(10,12,13,15)

128

Φ88”/2200

8.0/9.0

24x11x8(10,12,13,15)

132

Φ100”/2500

9.0

24x11x8(10,12,13,15)

140

Φ120”/3000

9.5

24x12x8(10,12,13,15)

160

Φ140”/3500

9.5

24x12x8(10,12,13,15)

180

Other specifications are available upon request.
