Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs

Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs
Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs

Large Image :  Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs

Product Details:
Place of Origin: Jiangxi, China
Brand Name: LINSING
Model Number: D400*10*50mm
Payment & Shipping Terms:
Minimum Order Quantity: 20 pieces
Price: $16.85/pieces 20-49 pieces
Contact Now

Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs

Description
Warranty: 3 Years Blade Thickness: 0.014in, 0.032in, 0.05in, 0.02in, 0.035in, 0.018in, 0.042in, 0.025in
Blade Width: 1 1/2IN, 3/4IN, 1/2in, 1 1/4IN, 5/8in, 3/8in, 1/8IN, 1/4in, 1in, 3/16in, Other Arbor Size: 7/8IN, 10mm, 5/8in
Teeth Per Inch: 10, 24 Teeths: 140, 144
Blade Length: 6in, 6 1/2in, 10in Blade Diameter: 18in, 12in
Edge Height: 0.315in(8mm), 0.472in(12mm) Process Type: HOT PRESS, High Frequency Welded, Laser Welded, Cold PRESS
Customized Support: OEM, ODM, OBM Finishing: Ti-coated
Size: D350/400/450mm Grade: Industrial
Segment Height: 7/10/12mm Technology: Silver Brazed
Advantage: High Quality Cutting Result Transport Package: Plastic Bag + Paper Box + Bubble Wrap + Carton Box
Specification: Diameter: 350~3000mm Blade: 350mm
Origin: Shangrao City, Jiangxi Province, China Feature: Long Lifespan And Fast Cutting Speed

Diamond Horizontal Blade For Marble

Horizontal cutting diamond saw blade is a tool used for horizontal and vertical stone cutting machine It is mainly used to cut marble in the horizontal direction.


Product feature:
1. Good in sharpness and efficiency with a long lifespan.
2. Fast cutting and refine edge cutting quality.
3.Excellent comprehensive cutting performance.


Product specification:

Blade

Diameter

(inch/mm)

Steel Core Thickness

(mm)

Segment Specification For Granite(mm)

Segment Specification For Marble(mm)

Segment No.(pcs)

Φ14”/350

7.5/3.0

40×4.4×10(15)

40×4.6×10

21

Φ16”/400

7.5/3.0

40×4.4×10(15)

40×4.6×10

24

Φ18”/450

7.5/3.0

40×4.4×10(15)

40×4.6×10

26

Φ20”/500

7.5/3.5

40×5.0×10(15)

40×5.5×10

30

Φ22”/550

4.0

40×6.0×10(15)

40×6.0×10

32

Φ24”/600

4.0

40×6.0×10(15)

40×6.0×10

36

Φ26”/650

4.0/4.5

40×6.0×10(15)

40×6.0×10

40

Other specifications are available upon request.

Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs 0Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs 1

Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs 2Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs 3Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs 4Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs 5Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs 6Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs 7Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs 8Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs 9Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs 10Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs 11Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs 12Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs 13Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs 14Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs 15Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs 16Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs 17Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs 18Industrial Grade Porcelain Blade 14 16 Inch Diamond Saw Blade Cutting Discs 19

Contact Us:
Caitlin Mi
Sales representative
WhatsApp/Wechat: 0086-18270195708
JiangXi LINSING Diamond Tools Co.,Ltd


            If you are interested in any of our products or would like to discuss a custom order, please feel free to contact us.
We are looking forward to forming successful business relationships with new clients from around the world in the near future.

Your special requirements are highly valued.
Please contact us for more details.
