Tools Diamond Core Drill Bit Hot Press Segmented Type for Marble Granite Quartz 6-125mm

Large Image : Tools Diamond Core Drill Bit Hot Press Segmented Type for Marble Granite Quartz 6-125mm

Product Details:

Place of Origin:	Jiangxi, China
Brand Name:	Linsing
Model Number:	Wet use core drill bit

Payment & Shipping Terms:

Minimum Order Quantity:	10 pieces
Price:	$2.80/pieces 10-99 pieces
Packaging Details:	The inner packaging is plastic film and the outer packaging is carton. If the customer orders a large quantity, it will be packed in wooden cases and wooden frames.
Supply Ability:	20000 Piece/Pieces per Day Dia.250-450 diamond circular saw blade

Contact Now

Tools Diamond Core Drill Bit Hot Press Segmented Type for Marble Granite Quartz 6-125mm

Description

Warranty:	None	Customized Support:	OEM, ODM, OBM
Type:	Core Drill Bit	Use:	Stone Drilling
Finish:	Other, Black Oxide, ZINC, Plain, Coating	Product Name:	Diamond Core Drill Bit
Application:	Drilling Holes	Material:	Diamond + Metal
Usage:	Wet	Size:	6-125mm
Shank:	Straight Shank	Color:	Customized Color
Feature:	High Speed.Straight Smooth Edge	Suitable For:	Stone, Concrete, Ceramic Tile, Masonry Etc.
Port:	Shanghai, Shenzhen, Ningbo, Xiamen, Etc

Diamond Core Drill Bit

Diamond core drill bits use super grade diamond, with high drilling efficiency They are commonly used for drilling hard materials such as stone, ceramic tile, reinforced concrete and so on

Product feature:
1. High efficiency, long life and no breaking of segments.
2. Sizes of adaptor: Dia.6, 8, 10mm shank, M14, M16, G1/2 ", 5/8 "-11.
3. Suitable for wet or dry use.
Product specification:

Diameter(mm)	Usable Length(mm)	Suggested R.P.M	Feed Speed(mm/min)
19-22	47	3000-3500	70-90
25	60	3000-3500	70-90
30-32	60	3000-3500	70-90
35-40	60	2000-2800	60-80
45-50	60	2000-2800	50-60
55	60	1500-2000	40-60
60	60	1500-2000	40-60
65	60	1500-2000	40-60
70	60	1500-2000	40-60
75-85	60	1500-2000	40-60
90	60	1500-2000	40-60
95-100	60	1000-1500	25-45
125	60	1000-1500	25-45

Other specifications are available upon request.
