6-125mm Vacuum Brazed Diamond Core Drill Bit for Stone Tile Granite Ceramic Marble

Large Image : 6-125mm Vacuum Brazed Diamond Core Drill Bit for Stone Tile Granite Ceramic Marble

Product Details:

Place of Origin:	Jiangxi, China
Brand Name:	Linsing
Model Number:	wet/dry use core drill bit

Payment & Shipping Terms:

Minimum Order Quantity:	10 pieces
Price:	$2.90/pieces 10-99 pieces
Packaging Details:	The inner packaging is plastic film and the outer packaging is carton. If the customer orders a large quantity, it will be packed in wooden cases and wooden frames.
Supply Ability:	20000 Piece/Pieces per Day Vacuum brazed diamond core drill bit

Contact Now

6-125mm Vacuum Brazed Diamond Core Drill Bit for Stone Tile Granite Ceramic Marble

Description

Warranty:	None	Customized Support:	OEM, ODM, OBM
Type:	Core Drill Bit	Use:	Stone Drilling
Working Length (mm):	Other	Finish:	Other, Black Oxide, ZINC, Plain, Vacuum Brazed
Product Name:	Vauum Brazed Diamond Core Drill Bit	Application:	Drilling Holes
Material:	Diamond + Metal	Usage:	Wet/dry
Size:	6-125mm	Shank:	Straight Shank
Color:	Customized Color	Feature:	High Speed.Straight Smooth Edge
Suitable For:	Stone, Concrete, Ceramic Tile, Masonry Etc.	Port:	Shanghai, Shenzhen, Ningbo, Xiamen, Etc

Vcuum Brazed Diamond Drill Bit

Diamond dry drill bit is made of high-quality diamond and adopts vacuum brazing to provide more efficient performance than traditional cemented carbide It can be used for drilling ceramic tiles, glass, marble and other materials.

Product feature:
1. High concentration of exposed diamond ensures long life and fast drilling.
2. Suitable for drilling reinforced concrete, natural stones, bricks, blocks & rock.
Product specification:

Diameter (Inch/mm)	Segment Height(mm)	Grit Size(#)	Connection
1/4"/6.3	8.0-10.0	35/50/60	shank/M14/5-8"-11/G/1/2"
3/8"/9.5	8.0-10.0	35/50/60	shank/M14/5-8"-11/G/1/2"
1/2"/12.7	8.0-10.0	35/50/60	shank/M14/5-8"-11/G/1/2"
5/8"/15.9	8.0-10.0	35/50/60	shank/M14/5-8"-11/G/1/2"
3/4"/19.0	8.0-10.0	35/50/60	shank/M14/5-8"-11/G/1/2"
1"/25.0	8.0-10.0	35/50/60	shank/M14/5-8"-11/G/1/2"
1-1/8"/29.0	8.0-10.0	35/50/60	shank/M14/5-8"-11/G/1/2"
1-1/4"/32.0	8.0-10.0	35/50/60	shank/M14/5-8"-11/G/1/2"
1-3/8"/35.0	8.0-10.0	35/50/60	shank/M14/5-8"-11/G/1/2"
1-1/2"/38.0	8.0-10.0	35/50/60	shank/M14/5-8"-11/G/1/2"
1-5/8"/41.0	8.0-10.0	35/50/60	shank/M14/5-8"-11/G/1/2"
1-3/4"/45.0	8.0-10.0	35/50/60	shank/M14/5-8"-11/G/1/2"
2"/51.0	8.0-10.0	35/50/60	shank/M14/5-8"-11/G/1/2"
2-1/4"/57.0	8.0-10.0	35/50/60	shank/M14/5-8"-11/G/1/2"
2-1/2"/63.0	8.0-10.0	35/50/60	shank/M14/5-8"-11/G/1/2"
2-3/4"/70.0	8.0-10.0	35/50/60	shank/M14/5-8"-11/G/1/2"
3"/76.0	8.0-10.0	35/50/60	shank/M14/5-8"-11/G/1/2"
3-1/2"/90.0	8.0-10.0	35/50/60	shank/M14/5-8"-11/G/1/2"
4"/100	8.0-10.0	35/50/60	shank/M14/5-8"-11/G/1/2"
4-4/5"/120	8.0-10.0	35/50/60	shank/M14/5-8"-11/G1/2"

Other specifications are available upon request
