11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry

Certification
China Jiangxi Linxing Diamond Tools Co., Ltd. certification
I'm Online Chat Now

11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry

11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry
11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry 11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry 11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry 11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry 11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry 11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry

Large Image :  11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry

Product Details:
Place of Origin: Jiangxi, China
Brand Name: Linxing
Certification: CE,ISO900
Model Number: S1-2-115A
Payment & Shipping Terms:
Minimum Order Quantity: 2000 pieces
Price: $0.39/pieces 2000-9999 pieces

11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry

Description
Customized Support: OEM, ODM, OBM Working Condition: Wet Quarrying
Matched Machinery: Quarry Wire Saw Machine Application: Granite
Size: 11.0mm; 11.5mm; 12.0mm Quality: High-quality
Assembly: Spring; Wire Rope Material: Diamond + Metal Powder
Service: Customized Service MOQ: 2000pcs

Product Description

Diamond Wire Saw Beads
The wire saw beads are processed through the advanced hot Isostatic processing which gives better diamond retention and higher tool reliability.

Product Features:
1. High bonding strength with great cutting efficiency and lifespan.
2. It is used to cut large-size blocks in quarry and factory processing.
3. Different bonds and diamond concentrations are available for different kinds of materials such as granite marble, limestone, travertine, concrete, etc.

1: LINXING diamond beads have diameters of 6.3, 7.2, 8.8, 9.5, 10.0, 11.0, 11.5, 12, 12.5mm and other specifications. other diameters available upon request for customers demand for cutting stone or reinforced concrete, etc., the all processing requirements.
2: Long life, such as products of the same industry, our beads have the characteristics of strong stability, sufficient rigidity, low wear and long life.
3: High cutting efficiency, bead compared to the segment for cutting, the efficiency can be increased several times or even ten times, and it saves more stone.
4: It is more environmentally friendly, especially in mining. If you use diamond wire saw for cutting, you can maximize the use of stone and reduce noise.

Diameter (mm) Working Layer Height(mm) Type
D12.5 6.4 Sinter
D12.0 6.4 Sinter
D11.5 6.4 Sinter
D11.0 6.2 Sinter/vacuum brazed
D9.0 6.0 Sinter
D8.3 6.0 Sinter
D7.3 6.7 Sinter
D6.3 6.7 Sinter
Diameter(mm) Beads/Meter Fixing Method Application
12.5 40 Rubber Reinforced concrete
12 40/37 Rubber Quarrying
11.5 40/37 Spring,rubber,plastic Quarrying
11 37 Spring,plastic Quarrying/squaring
10.5 37 Spring,plastic Squaring
8.8 37 plastic Profiling
8.5 37 plastic Block/slab cutting&profiling
8.8 37 plastic Block/slabcutting&profiling
7.2 37 plastic Multi wire
6.3 37 plastic Multi wire
5.3 37 plastic Multi wire

11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry 0

11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry 1

11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry 2

11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry 3

11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry 4

11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry 5

11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry 6

11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry 7

11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry 8

11.5mm Sintered Diamond Bead for Mining Wire Saw Accessories in Granite Quarry 9
